Optimized for the LVD Easy-Form/CADMAN series, enabling high-precision, high-speed bending and collaborative operation across multiple tool libraries. Adapts to the forming requirements of 2.5mm stainless steel boxes, meets the corrosion resistance requirements of ship plate bending, and supports multi-batch production of customized sheet metal parts.
Machine Matching: Adapts to a working speed of 21mm/s and a bending accuracy of ±0.3 degrees, supporting self-mounted top tools and multi-segment V-die quick-assembly systems. Compatible with LVD CNC system versions V8.0 and above, enabling real-time data interaction with CADMAN software and improving programming efficiency.
Recommended Material Thickness: Select the V-groove according to plate thickness × 7~9 (e.g., 1.5mm SUS304 stainless steel with a 10.5-13.5mm groove, 2mm AL6061 aluminum plate with a 14-18mm groove), adapting to 2.5mm stainless steel box forming, supporting precision machining with a thickness range of 0.3-8mm.
Indentation-free solution: Employing a vacuum lower die + localized soft lining combination, a 0.2mm silicone pad achieves zero damage to the aluminum plate and stainless steel surface; optional R0.8 tip punch + carbide lower die reduces tool marks by over 80%.
Applications: Bending of marine 5083 aluminum-magnesium alloy plates, forming of stainless steel medical device enclosures, customized control cabinet sheet metal processing, precision forming of 5G antenna vibrators.
